| Indoor |
ASW-09MAR3DI |
ASW-12MAR3DI |
ASW-18MAR3DI |
ASW-24MAR3DI |
| Outdoor |
AS-09MAR3DI |
AS-12MAR3DI |
AS-18MAR3DI |
AS-24MAR3DI |
| Cooling Capacity |
Rated(Min-Max) |
Btu/h |
10000 (2050-13650) |
12300 (4100-13650) |
18000 (4440-18000) |
24400 (6140-24560) |
| Power consumption |
W |
960 (200-1200) |
1170 (400-1450) |
1730 (240-2200) |
2260 (230-2700) |
| Running current |
A |
4.4(0.56-9.0) |
5.1 (2.0-8.0) |
7.7 (2.3-9.0) |
9.7 (1.0-16) |
| CSPF(Cooling seasonal performance factor) |
Wh/Wh |
4.81 |
4.83 |
4.78 |
5.19 |
| Energy Efficiency Star Rating |
 |
 |
 |
 |
| Power supply |
V,Hz,Ph |
220-240V~,50Hz,1Ph (power supply to indoor) |
| Indoor unit |
Indoor air flow(H) |
m3/h(cfm) |
600 (353) |
650 (382) |
950 (559) |
1300 (765) |
| Indoor Sound level(H/L/S) |
dB(A) |
40/32/24 |
41/33/24 |
47/36/32 |
51/38/34 |
| Dimensions(W*D*H) |
mm |
768*299*200 |
827*299*200 |
997*321*222 |
1140*334*229 |
| Packing(W*D*H) |
mm |
831*371*282 |
891*371*282 |
1070*385*312 |
1210*400*327 |
| Net/Gross weight |
Kg |
7.5/9 |
8/12 |
11/13 |
13/17 |
| Outdoor unit |
Outdoor Sound level |
dB(A) |
51 |
52 |
53 |
58 |
| Dimensions(W*D*H) |
mm |
703*233*455 |
703*233*455 |
705*279*530 |
900*350*700 |
| Packing(W*D*H) |
mm |
760*305*510 |
760*305*510 |
825*345*595 |
1015*425*762 |
| Net/Gross weight |
Kg |
16/18 |
16/18 |
23/26 |
37/40 |
| Refrigerant Charge |
g |
R32/360g |
R32/360g |
R32/690g |
R32/1050g |
| Design pressure |
MPa |
4.3/2.5 |
4.3/2.5 |
4.3/2.5 |
4.3/2.5 |
| Refrigerant piping |
Liquid side/Gas side |
mm(inch) |
Φ6.35/Φ9.52(1/4"/3/8") |
Φ6.35/Φ9.52(1/4"/3/8") |
Φ6.35/Φ12.7(1/4"/1/2") |
Φ6.35/Φ12.7(1/4"/1/2") |
| Max.difference pipe length |
m |
25 |
25 |
25 |
30 |
| Max.difference in level |
m |
10 |
10 |
10 |
20 |
| Indoor-Outdoor connection wiring(Not included) |
4x1.0mm2 |
4x1.0mm2 |
4x1.5mm2 |
5x2.5mm2 |
| Power supply wiring(No included) |
3x1.0mm2 |
3x1.0mm2 |
3x1.5mm2 |
3x2.5mm2 |
| Thermostat type |
Wireless Remote Control (Wifi/Remote Wired Controller optional) |
