Piston

  • PCB REMOVABLE
    Independent structure design, so it's convenient for us to maintain by screwing off one screws to remove it.
  • LARGE AIR
    Experience powerful airflow that reaches you no matter where you sit.
  • FAST COOLING
    Quick chill with high-frequency compression.
Find the nearest dealer Find the nearest dealer

In store stocks availability are subject to respective retailers.

PCB REMOVABLE
Independent structure design, so it's convenient for us to maintain by screwing off one screws to remove it.
LARGE AIR
Experience powerful airflow that reaches you no matter where you sit.
FAST COOLING
Quick chill with high-frequency compression.
GOLDEN FIN
Anti-corrosion for long-lasting durability.

Specifications

Model Indoor ATW24C4R1-1AE ATW30A4R1-1AE ATW36A4R1-1AE
Outdoor AT24C4R1-1AE AT30A4R1-1AE AT36A4R1-1AE
Power Supply V/Hz/Ph 220-240V/1/50Hz 220-240V/1/50Hz 220-240V/1/50Hz
Star Rating ★★ 2 Star ★★ 2 Star ★ 1 Star
Capacity Cooling(T1) Btu/h 24907 32001 32997
W 7300 9379 9671
Cooling(T3) Btu/h 21800 27400 28300
W 6380 8030 8294
Electric Data Rated Cooling Power Input(T1) W 2120 2700 2796
Rated Cooling Current(T1) A 9.4 12.5 14
Rated Cooling Power Input(T3) W 2420 3030 3356
Rated Cooling Current(T3) A 11 14 15.5
Performance EER(T1) (Btu/h)/W 11.74 11.84 11.77
W/W 3.44 3.47 3.45
EER(T3) (Btu/h)/W 9.01 9.05  8.43
W/W 2.64 2.65 2.47
Indoor Unit Indoor Air Flow m³/h 1650 2000 2000
Noise Level dB(A) 51 53 54
Net Dimension (W*D*H) mm 1250*360*253 1460*375*270 1460*375*270
Net Weight Kg 16 20 20
Outdoor Unit Net Dimension (W*D*H) mm 970*803*370 970*805*395 970*805*395
Net Weight Kg 70 70 72.5
Refrigerant Type R410A R410A R410A
